CATEGORIES OF INSTRUMENT LANDING SYSTEM (ILS)
The article expounds on Instrument Landing Systems (ILS) as applied in aviation sector
AVIATION ARTICLES
Boniface Kipchumba Mibei
3/1/20252 min read
Understanding ILS Categories
Instrument Landing Systems (ILS) are classified into categories based on the level of precision they provide and the minimum visibility conditions required for landing. These categories are particularly important for pilots and air traffic controllers in ensuring safe landings, especially in poor weather conditions.
Category I (CAT I)
Decision Height (DH): 200 feet (≈ 60 meters) above ground level.
Runway Visual Range (RVR): At least 550 meters.
Usage: This category provides basic precision approach guidance. It is commonly used at most airports and requires pilots to have a visual reference of the runway before descending below the decision height.
Equipment Required: Standard ILS receivers in aircraft, along with ground-based localizer and glideslope systems.
Category II (CAT II)
Decision Height (DH): As low as 100 feet (≈ 30 meters).
Runway Visual Range (RVR): At least 300 meters.
Usage: This allows for landings in more challenging conditions than CAT I. Pilots must still have some visual reference before descending below the decision height.
Equipment Required: Enhanced aircraft avionics, auto-land capabilities in some cases, and improved airport lighting systems.
Category III (CAT III)
This is the highest level of precision landing system, designed for extremely poor visibility conditions. It is further divided into three subcategories:
CAT IIIa
Decision Height (DH): As low as 50 feet (≈ 15 meters).
Runway Visual Range (RVR): At least 175 meters.
Usage: This category allows for landings in very low visibility but still requires a slight visual reference before touchdown.
Equipment Required: Advanced auto-land systems and high-precision ground installations.
CAT IIIb
Decision Height (DH): As low as 15 feet (≈ 5 meters).
Runway Visual Range (RVR): At least 50 meters.
Usage: This enables landings in extremely poor visibility, with minimal pilot intervention.
Equipment Required: Aircraft must have full auto-land capability, and airports must have advanced ground guidance systems.
CAT IIIc
Decision Height (DH): 0 feet (no minimum).
Runway Visual Range (RVR): 0 meters (no minimum).
Usage: Theoretically allows landings in zero visibility conditions (fog, heavy snow, or darkness) without requiring any visual reference. However, practical implementation is rare due to the need for advanced ground movement guidance systems that many airports lack.
Equipment Required: Fully automated landing and taxiing systems, which are not widely available at most airports
In conclusion, the advancement of ILS technology has significantly improved aircraft landing capabilities, especially in adverse weather conditions. While CAT IIIc offers the potential for zero-visibility landings, its widespread use is limited by airport infrastructure and the need for advanced taxiing guidance systems.
